Cementitious Raised Floor



Unifloor™ Cementitious panel has become the preferred choice for architects, specifiers and end users due to its enhanced performance characteristics compared to a standard wood core or calcium silicate panel. The Cementitious core is inherently less susceptible to fluctuations in humidity and temperature than a wood core product. This assists with on-site installation programming and therefore offers greater flexibility.

Design Data

TILES
  • All steel construction & cavity filled with light weight cement slurry
  • Top and Bottom sheet manufactured out of GI sheet with epoxy coating for lifetime rust protection
  • Bottom plate has 64 inverted embossing with spot welding for superior strength and greater fire resistance,
  • Panels rest on the grid formed by the stringers which are bolted onto the pedestals for rigid lateral stability.
PEDESTAL
  • All steel construction zinc plated
  • Threaded bolt & nut for leveling adjustment on top & bottom
  • Various heights are available 80mm to 1200mm
  • Pedestal carry more than 2200 kg axial load without any deformation
STRINGER
  • All steel construction
  • Seamless rectangular shape for Panel support
  • Unique Benefits
  • Exceptionally high rolling load capacity
  • Panels are imprinted with load specifications for genuinity
  • Non-combustible: Fire Resistant Class 0
  • Suitable for areas with high humidity and other specialist applications
  • Complies with All International Regulations
  • Zinc Whisker Free Technology for Lifetime Protection
  • Four sides are protected by edge trim
  • No volatile organic compounds (VOC’s) used
  • Exceeds PSA MOB PF2 PS/SPU specification standards

Technical Data

TILES
Size: 600 x 600mm
Thickness: 33-35mm
Top: High Pressure Anti Static Laminate / Vinyl / Bare

PEDESTAL
Top plate size: 75mm x 75mm x 3.5mm
Bottom plate size: 100mm x 100mm x 2mm
Pipe Outer Diameter: 25 mm
Height: 100 to 1200mm

STRINGER
Size: 21mm x 30mm x 570mm
Thickness: 0.80mm
Shape: seamless rectangular shape
Hole Distance: 550mm (centre to centre)

Recommended Applications
  • Light Duty - General office areas
  • Medium Duty - High density / populated office commercial areas
  • Heavy Duty - Plant rooms, server rooms
  • Extra Heavy - Specialist applications and exceptionally heavy equipment requirements


Features of Unifloor™  Steel Cementitious panel

  • Fire proof
  • Widely used in computer rooms
  • Fast and accurate installation
  • Excellent anti-static performance
  • Can eliminate the static electricity produced by the servers when they are working
  • The stability of the servers will be maintained. Thus the life span of the servers will be prolonged.
  • System is “Lay In” system, It will greatly facilitate the plenum maintenance.
  • Easy to remove & re-fix since corners are not screwed to the pedestal head
  • Tiles are supported in all the four sides since our system is stringer based which do not undulate/bend at the sides
  • Special weather coating on back surface of the tiles for lifetime protection
  • The panel sizes are controlled with great precision, which assures the free interchange of the panels
  • With convenient wire layout and various outlet boxes, the system can optimize the cabling in computer rooms.
  • Eco-friendly

Typical Uses
  • Auditorium space
  • Date Centers
  • UPS Rooms
  • Server rooms
  • Individual offices
  • Ticketing Counters
  • Clean Room


Unifloor™ Quality Assurance

Our system is tested and certified to comply with Global Governing body, CISCA's test procedures for Raised Access Flooring Systems. It is tested by one of world's Largest Test house, PSB Singapore and NSIC, a prominent
Government run testing house in New Delhi. This ensures that the testing, assessment and certification criteria utilized meets all the relevant quality, safety and performance standards demanded by our clients.

Performance Selection Chart

Unifloor Filled Steel Cementitous Core Raised Floors

Panel Type

Panel Grade

Design Load (kN)

Point Load (kN)

Impact Load (kG)

Safety Factor

Uniform Load (kN/m2)

FS800H

Medium

3.6

3.6

50

3

13.6

FS1000H

Med Heavy

4.5

4.5

50

3

20

FS1250H

Heavy

5.5

5.5

50

3

25

FS1500H

Extra Heavy

6.6

6.6

50

3

30
